EnGenius EAP600
High-Powered, Long-Range Ceiling Mount, Dual-Band N600 Indoor Access Point

EnGenius EAP600 Product Image

EnGenius Indoor Access Points / Bridges
EnGenius EAP600
EnGenius EAP600 High-Powered Dual-Band N600 Indoor AP/Client Bridge
#EAP600
Our Price: $119.00
EnGenius EAP600 High-Powered Dual-Band N600 Indoor AP/Client Bridge, 3 Pack
#EAP600-3PACK
Our Price: $329.00
EnGenius Wi-Fi Bundle Kits
EnGenius N-EAP600 Kit
Includes EPE5818Gaf PoE injector + EAP600 High Power Gigabit Wired Wireless-N Dual Band Access Point/WDS with Embedded Antenna, Smoke Detector Design
#N-EAP600 Kit
Our Price: $159.00

More pricing below, click here!

Overview:

The X-treme SMB EnGenius EAP600 is a concurrent dual-band 2.4+5GHz Wireless-N Indoor Access Point that features high transmit RF power (29 dBm on 2.4GHz and 26 dBm on 5GHz) for long range connectivity. With wireless speeds up to 300Mbps on each radio and a Gigabit port for connecting to a switch or router it’s ideal for expanding a network with additional bandwidth to support additional users.

With the dual-band Wireless-N EAP600 companies can now offer employees, guests, staff or students more expanded options for users who transfer large files within the network or use other bandwidth intensive applications like streaming HD video. The AP’s Gigabit Ethernet (10/100/1000) port also offers greater bandwidth capacity and faster data transfers through the network. This high-powered Access Point/WDS Bridge with its enhanced receive sensitivity and internal MIMO (Multiple In/ Multiple Out) antenna array extends wireless coverage and enhances connectivity to client devices even in areas where connections have been previously challenging or non-existent and in some buildings it’s wireless signal can penetrate up to 3 floors. This makes the EAP600 ideal for extending networks within large or multi-story buildings or expansive, client-intensive facilities like hotels, resorts, hospitals, office buildings, universities or other multi-building campus facilities.

The 2012 reddot design award-winning EAP600The 2012 reddot design award-winning EAP600 has been designed to appear as a low-profile smoke detector and thus unobtrusively blend in with other common building infrastructure appliances. Because the EAP600 is designed for deployments on ceilings where power outlets may be scarce, it is also PoE (Power- over-Ethernet) IEEE 802.3af/at capable when used with a PoE injector or PoE switch.

The EAP600 can be configured to operate in several different modes – as a dual-band Wireless-N Access Point, a WDS Access Point, or Repeater. It operates concurrently in the 2.4GHz and 5GHz frequency spectrums supporting 802.11a/b/g/n standards.

  • Concurrent Dual-Band 300+300Mbps Support - 802.11N dual radio concurrent operation in 2.4GHz and 5GHz for maximum wireless throughput performance
  • MSSID and VLAN Support - Up to 8 BSSIDs per radio with 802.1q VLAN tagging
  • 4 x Internal Antennas - 4x 5dBi Internal antennas optimizing maximum RF performance
  • Aesthetic Design Enclosure - "Smoke Detector" appearance and easy mounting mechanism with T-rail, ceiling, and wall mount kits
  • High-Power, Long-Range Wi-Fi - 29 dBm for 2.4GHz, 26 dBm for 5GHz RF Tx power provides more than twice the Wi-Fi coverage over mainstream competitors
  • 802.3af/at PoE Compatible - Supports Power over Ethernet (IEEE 802.3af/at) and allows deployment in areas where power outlets are not available
  • Simplified Wireless Network Management - Includes SNMP-based wireless access point management software EZ Controller

Specifications:

EnGenius EAP600H Specifications

EnGenius EAP600 Specifications
Standards IEEE802.11b/g/n on 2.4 GHz
IEEE 802.11a/n on 5 GHz
IEEE802.3at/af
Memory Capacity Memory: 128 MB
Flash Memory 16 MB
Antenna Internal Omni-Directional Antennas
5 dBi on 2.4 GHz & 5 GHz
Physical Interface 1 x 10/100/1000 Gigabit Ethernet Port
1 x Reset Button
1 x Power Connector
Physical Security Kensington Security Slot
LED Indicator 1 x Power
WLAN (Wireless Connection)
2.4 GHz
5 GHz
1 x LAN
Power Source External Power Adapter
DC IN, 12V/2A
IEEE 802.3at Compliant Source
Mounting Ceiling Mount
Wall Mount
Wireless & Radio Specifications
Operating Frequency Dual-Radio Concurrent 2.4GHz & 5GHz
Operation Modes Access Point
Frequency Radio 2.4GHz: 2400MHz ~ 2835MHz
5GHz: 5180MHz ~ 5240MHz, 5260 ~ 5320MHz, 5500MHz ~ 5700MHz, 5745MHz ~ 5825MHz
Transmit Power Up to 29 dBm on 2.4 GHz
Up to 26 dBm on 5 GHz
Max transmit power is limited by regulatory power
Radio Chains/Spatial Streams 2x2:2
Supported Data Rates (Mbps) 2.4 GHz: Max 300
5 GHz: Max 300
802.11b: 1, 2, 5.5, 11
802.11a/g: 6, 9, 12, 18, 24, 36, 48, 54
802.11n: 6.5 to 300 (MCS0 to MCS23)
Supported Radio Technology 802.11b: Direct-Sequence Spread-Spectrum (DSSS)
802.11a/g/n: Orthogonal Frequency-Division Multiplexing (OFDM)
Channelization 802.11n with 20/40 MHZ channel width
802.11a/b/g with 20 MHZ channel width
Supported Modulation 802.11b: BPSK, QPSK, CCK
802.a/g/n: BPSK, QPSK, 16-QAM, 64-QAM
Management
Multiple BSSID Supports up to 8 SSIDs per radio
VLAN Tagging Supports 802.1q SSID-to-VLAN tagging
VLAN Pass through
QoS WMM
SNMP v1, v2c, v3
MIB I/II, Private MIB
Management Features Deployment Options
Standalone (Individually Managed)
Configuration Web Interface (HTTP)
CLI (Telnet)
Control Features Auto Reboot
Firmware Upgrade: Web interface or CLI (FTP/HTTP)
Email Alert
Auto Channel
Auto Transmit Power
Band Steering
Syslog Notification
Backup / Restore
Security WPA/WPA2 Enterprise
Hide SSID in beacons
MAC Address Filtering
Https Support
Station Separation
Environmental & Physical
Temperature Range Operating: 32°F to 104°F (0°C to 40°C)
Storage: -4°F to 140°F (-20°C to 60 °C)
Humidity (non-condensing) Operating: (90% or less
Storage: 90% or less
Device Dimensions & Weights
Device Weight: 0.65 lbs.
Diameter: 6.36” (161.54 mm)
Height: 1.64” (41.66 mm)
Package Contents EAP600 Dual-band Neutron Series solution Wireless N600 Managed Indoor Access Point
12V/2A Power Adapter
T-Rail Mounting Kit
Ceiling and Wall Mount Screw Kit
Mounting Bracket
RJ-45 Ethernet Cable
Quick Installation Guide
Certifications FCC
CE
Warranty 1 Year

Product Comparison:


Model EAP1750H EAP1200H EAP900H EAP600 EAP350 EAP300
Frequency 802.11 a/b/g/n/ac 802.11 a/b/g/n/ac 802.11 a/b/g/n 802.11 a/b/g/n 802.11 b/g/n 802.11 b/g/n
Maximum Data Speed 450 + 1300Mbps 300 + 867Mbps 450 + 450Mbps 300 + 300Mbps 300Mbps 300Mbps
LAN Interface 10/100/1000 10/100/1000 10/100/1000 10/100/1000 10/100/1000 10/100
Encryption WPA2 WPA WEP WPA2 WPA WEP WPA2 WPA WEP WPA2 WPA WEP WPA2 WPA WEP WPA2 WPA WEP
SDRAM 128 MB 128 MB 128 MB 64 MB 32 MB 32 MB
FlashMemory 16 MB 16 MB 16 MB 16 MB 4 MB 4 MB
RF Power (dBm) 2.4 GHz: 28 dBm
5 GHz: 28 dBm
2.4 GHz: 26 dBm
5 GHz: 26 dBm
2.4 GHz: 28 dBm
5 GHz: 28 dBm
2.4 GHz: 29 dBm
5 GHz: 26 dBm
29 dBm 29 dBm
Receive Sensitivity ≤-94 dBm ≤-94 dBm ≤-94 dBm ≤-94 dBm ≤-94 dBm ≤-92 dBm
Antenna 6 x 5 dBi Sectorized 3D 6 x 5 dBi Sectorized 3D 6 x 5 dBi Sectorized 3D 4 x 5 dBi Embedded 2 x 5 dBi Embedded 2 x 5 dBi Embedded
Transmit Power (mW) 630mW/630 mW 400mW/400mW 630mW/630mW 800mW/400mW 800mW 800mW
Operation Modes Access Point, WDS AP, WDS Bridge Access Point, WDS AP, WDS Bridge Access Point, WDS AP, WDS Bridge Access Point, WDS AP, WDS Bridge Repeater Access Point, WDS AP, WDS Bridge Repeater Access Point, WDS AP, WDS Bridge Repeater
Number of SSID 16 (8 per radio) 16 (8 per radio) 16 (8 per radio) 16 (8 per radio 8 4
802.1q zVLAN
QoS
AP Management Software (EZC)
PoE 802.3at 802.3at 802.3at 802.3at/af 802.3af 802.3af
User Support Up to 50 on each radio Up to 50 on each radio Up to 50 on each radio Up to 50 on each radio Up to 50 Up to 50

Documentation:

Download the EnGenius EAP600 Datasheet (PDF).
